2005 — 2011
2.5L I6 (N52B25)
Petrol
Listen for rhythmic 'ticking' from the engine top-end | Note: Commonly known as hydraulic lifter tick; while usually not fatal, it indicates poor oil flow in early N52 cylinder heads.
Inspect Oil Filter Housing Gasket (OFHG) for leaks | Note: If oil leaks onto the drive belt, it can snap and be sucked into the engine via the front seal, causing catastrophic failure.
Test electric water pump operation | Note: These fail without warning; if the electric fan runs at max speed constantly, the water pump is dying. Don't drive it.
Check for oil in the eccentric shaft sensor connector | Note: Located under the engine cover; oil ingress here can fry the expensive Valvetronic motor and ECU.
Replace spark plugs and check for VANOS solenoid clogging which causes hesitant acceleration.
Mandatory replacement of the electric water pump and thermostat to avoid roadside stranding.
Inspect the plastic valve cover for hairline cracks; the cover itself often warps, not just the gasket.
Change oil every 10,000km to prevent sludge buildup in the VANOS system.
Replace the 'Mickey Mouse' coolant flange with an aluminum upgrade.
Service the automatic transmission (ZF 6-speed) including a new pan/filter.
Clear sunroof and battery tray drains to prevent expensive electronic failures.
Ensure the battery is 'registered' if replaced to protect the alternator.
Estimated repair costs if issues arise
The single most common failure that leaves E90 owners stranded.
The plastic cover perishes; replace the whole unit to save on repeated labor.
Essential for NZ chip-seal roads to stop steering vibrations and wandering.
