2000 — 2005
3.2L V6 (M112)
Petrol
Check transmission connector plug leakage | Note: Inspect the automatic transmission 13-pin electrical connector pilot bushing for fluid leaks. If left unchecked, oil can wick up the wiring harness via capillary action and flood the Transmission Control Unit (TCU), destroying the electronics.
Assess engine idle smoothness and ignition | Note: The M112 V6 utilizes a twin-spark design requiring 12 spark plugs. Any rough idling or subtle misfires typically indicate heavily neglected maintenance, aged ignition leads, or failing coil packs.
Operate climate control and listen to the dash | Note: Cycle through all directional climate vents and listen for distinct clicking or snapping sounds from behind the dashboard. This indicates broken plastic blend door actuators, a legendary W203 fault requiring complete dashboard removal to repair.
Examine front suspension control arms and alignment | Note: Navigate rough surfaces to check for front-end knocking noises. The heavy V6 strains the front control arm and caster arm rubber bushings, which perish quickly under demanding New Zealand road conditions.
Major threshold requiring a full cooling system overhaul. The factory radiator (especially valeo units prone to cross-contamination) and water pump should be checked, alongside a preventative differential fluid service.
The dual-spark ignition system (all 12 plugs and wires) should be fully refreshed. Original hydraulic engine mounts will likely have collapsed by this stage, leading to heavy drivetrain vibrations transmitted into the cabin.
Inspect the crankshaft harmonic balancer pulley for severe rubber degradation or separation, and completely refresh the front and rear suspension link assemblies to restore factory road manners.
Verify the complete replacement of all 12 spark plugs every 60,000km to protect the ignition system.
Ensure the 5G-Tronic transmission fluid, filter, and connector bushing are serviced regularly every 60,000km.
Regularly inspect the outer rubber ring of the harmonic balancer pulley for cracking or separation.
Clear the structural drain plugs underneath the windscreen wiper cowl to prevent water flooding into the passenger SAM module.
Monitor the condition of the valve cover gaskets and breather covers, as hardened factory RTV seals cause persistent oil leaks.
Estimated repair costs if issues arise
Common electrical failure within the 5G-Tronic speed sensor array that triggers hard limp-home mode. Requires valve body removal, clean fluid, and a new conductor plate.
The replacement parts are cheap, but the sheer labor intensity of stripping the entire structural dashboard drives up independent specialist repair costs significantly.
Higher maintenance allocation required due to the dual-plug-per-cylinder configuration. Factor in replacement of brittle ignition lead wires at the same time.
Replacing perished front lower control arms, caster arms, and associated sway bar links to clear WOF failure points and stop front-end knocking.
