2013 — 2015
6.2L V8 (M156) - 507bhp (SLS Internals)
Petrol
Audit AMG SpeedShift MCT wet-clutch engagement | Note: Cycle through Comfort, Sport+, and Manual modes. The Edition 507 features a wet multi-plate start-off clutch instead of a torque converter; any prominent shunting, delayed bite-point, or harsh lunging in traffic means the clutch pack requires adaptation reset or is burnt.
Check two-piece composite front brake rotors for thermal warp | Note: Perform high-speed braking on a safe, straight stretch. Edition 507 utilizes unique lightweight compound rotors with aluminum hubs; feel for any steering wheel oscillation or pedal pulsation, indicating warped front discs that are extremely costly to replace.
Scan top-end valvetrain for forged component lifter noise | Note: Listen to the cylinder banks when fully warm. The 507 utilizes forged pistons, lightweight connecting rods, and a lightened crankshaft from the SLS AMG; ensure there is no deep mechanical knocking or lifter ticking, which indicates premature cam lobe flat-spots.
Inspect dry-sump lookalike oil cooler lines for seepage | Note: Examine the under-bumper front auxiliary oil cooler core and connecting hardlines. High-velocity driving conditions on coarse NZ chip roads can lead to stone-impact micro-leaks or rubber line crimp perishing, leading to rapid engine oil pressure loss.
Critical milestone for the high-stress MCT transmission. A meticulous fluid and pan filter exchange is mandatory to clear out friction plate debris. Replace spark plugs completely to preserve stable combustion.
Chassis compliance threshold. The stiff, track-focused AMG performance suspension bushings and rear subframe mounts require close inspection for rubber delamination or structural tearing under 507hp load profiles.
Comprehensive powertrain evaluation. Although factory-immune to early head bolt failures, the high-revving valvetrain (cam adjusters and lifter faces) and primary cooling system radiator tanks must be inspected for thermal stress micro-cracks.
Perform engine oil fluid and filter changes strictly every 10,000km or annually using certified AMG-spec full synthetic lubricants.
Always allow the oil temperature gauge on the central cluster to fully transition from blue to white before applying wide-open throttle inputs.
Routinely inspect the inner-edge tire wear patterns on the rear axle; the high-camber AMG factory geometry accelerates inner wire exposure.
Clean and lubricate the panoramic sunroof guide tracks annually to avoid electronic motor strain or drain tube blockages.
Enforce standard 24-month brake fluid flushes using high-boiling-point fluid to secure the electronic brake booster handoff dynamics.
Estimated repair costs if issues arise
Extreme severity maintenance tariff. The 507's unique weight-optimized composite brake hardware is exceptionally expensive to source through authorized NZ dealer lines and cannot be machined down.
Highly specialized transmission intervention. If the multi-plate clutch system suffers severe slippage from past abuse or launch-control overuse, replacement requires expert gearbox teardown and modular calibration syncing.
Advanced top-end valvetrain restoration. Despite late-run engine manufacturing improvements, high-rpm lifter bore friction remains a wear factor. Rectification requires matching OEM camshaft profiles and upgraded black-series buckets.
Continuous handling protection expense. To safely manage 507hp on local wet asphalt, top-tier compounds like Michelin Pilot Sport Cup 2 or 5 are essential. Budget for frequent rear replacement cycles.
