2000 — 2003
1.5L I4 (TUD5)
Diesel
Find an uneven Kiwi backroad or empty carpark, turn the radio off, and listen closely for metallic knocking, clicking, or creaking sounds from the rear of the car. Step outside and visually inspect if the rear wheels are leaning inwards at the top (negative camber). | Note: The rear trailing arm needle bearings are notorious for wearing out, allowing moisture in and seizing. If caught late, it wears into the axle tube itself, requiring a complete rear axle beam rebuild or replacement, which is highly expensive in NZ due to scarce parts.
Allow the car to idle up to operating temperature. Check the coolant expansion tank for signs of bubbling, 'mayonnaise-like' oil sludge under the oil filler cap, or excessive sweet-smelling white smoke from the exhaust. | Note: The 1.5L TUD5 diesel features an aluminum block with cast-iron liners. It is extremely sensitive to overheating. Any cooling system neglect quickly leads to head gasket failure or a warped cylinder head.
Ensure the engine is completely cold before starting. Turn the key to 'ON', observe how long the glow plug light remains illuminated, and listen for how quickly the engine fires up and whether it runs smoothly or coughs with gray smoke. | Note: A hard cold-start accompanied by smoke usually indicates worn glow plugs or a faulty pre-heating relay. In colder NZ climates (especially the South Island), tired glow plugs will leave you stranded.
Inspect the boot floor under the spare wheel carpet, the sills, and the front inner wing structures beneath the battery tray using a torch. | Note: While Peugeot's galvanizing was decent for the era, water ingress from deteriorated tail light seals or sunroof drains can cause severe rust in the boot floor, leading to a structural WOF failure.
Minor Service: Replace engine oil (10W-40) and oil filter. Drain any water from the fuel filter housing. Clean the air filter housing and inspect front brake pads for wear.
Intermediate Service: Replace the fuel filter and air filter elements. Flush and renew the brake fluid and engine coolant. Inspect rear brake drums for hydraulic wheel cylinder leaks and adjust the handbrake cable.
Major Service: Crucial replacement of the timing belt, tensioner, and water pump (the TUD5 is an interference engine; a belt failure destroys the cylinder head). Check and adjust valve clearances using shims, and replace the manual gearbox oil.
Check and clear the cowl/scuttle drains below the windscreen weekly to prevent rainwater from leaking into the cabin and shorting out the fuse box.
Monitor the coolant level in the expansion tank weekly; the TUD5 has virtually zero tolerance for low coolant volumes.
Regularly clean and tighten the main gearbox-to-chassis earth strap to prevent erratic electrical issues and slow cranking speeds.
Inspect the rubber fuel lines in the engine bay for cracking or air leaks, which can introduce air bubbles into the mechanical injection system and cause stalling.
If aftermarket grease nipples have been retrofitted to the rear axle beam, grease them every six months to prevent trailing arm bearing failure.
Estimated repair costs if issues arise
Required when trailing arm needle bearings seize and score the axle shafts. Sourcing a used beam in NZ is very difficult, so importing a rebuild kit and paying for specialist labor is the standard path.
Preventative maintenance required every 5 years or 80,000–100,000 km. Essential to avoid catastrophic engine failure.
Necessary if the engine has been overheated due to a failed radiator fan switch or water pump leak. Includes pressure testing and skimming the cylinder head.
