2013 — 2016
1.2L I3 (EB2)
Petrol
Inspect the engine oil filler port with a torch before starting; look closely at the exposed section of the timing belt running through the oil. | Note: The EB2 'wet belt' runs directly through the engine oil. It is notorious for degrading, cracking, and shedding rubber fibers which clog the oil pickup, leading to oil starvation and complete engine failure.
Perform a firm, controlled stop from 50 km/h in a safe area to evaluate brake pedal feel, stiffness, and overall stopping power. | Note: Fibers from a disintegrating timing belt often clog the brake vacuum pump oil feed, causing a sudden loss of braking assistance (a rock-hard pedal), which is a major safety recall item in NZ.
Accelerate moderately in a high gear from low RPM (e.g., 50 km/h in 4th gear) and listen for metallic pinging, engine hesitation, or stuttering. | Note: The direct-injection EB2DT/DTS turbo variants suffer from carbon buildup on intake valves, leading to Low-Speed Pre-Ignition (LSPI/Super-Knock), which can damage spark plugs and crack pistons.
Drive through stop-and-go conditions, ensuring the vehicle executes smooth upshifts and downshifts between 1st, 2nd, and 3rd gears. | Note: While the Aisin EAT6 automatic transmission is generally robust, neglected fluid changes (often overlooked as 'sealed for life' by NZ owners) can lead to jerky shifts and premature valve body wear.
Minor service. Essential to check the timing belt width using the official PSA gauge tool. Oil must be changed using only PSA B71 2312 spec oil (0W-30) to prevent belt degradation.
Intermediate service. Replace spark plugs (crucial to prevent coil pack stress and LSPI), engine/cabin air filters, and inspect the front brake pads/rotors for wear.
Major service milestone. Replace the timing belt, belt tensioners, and water pump (interval is 6 years or 100,000km). Have the oil sump dropped and the oil pickup strainer cleared of any belt debris.
Use strictly PSA B71 2312 or B71 2010 certified lubricants (such as Total Quartz Ineo First 0W-30) to protect the wet timing belt.
Measure the timing belt width at every oil change interval using the PSA belt wear gauge tool.
Perform intake valve decarbonisation (walnut blasting) every 50,000km to maintain performance and prevent pre-ignition issues.
Replace spark plugs every 30,000km or 2 years to minimize the risk of ignition failure and subsequent unburnt fuel damaging the catalytic converter.
Flush the EAT6 automatic transmission fluid every 60,000km to ensure shifting refinement and longevity.
Estimated repair costs if issues arise
Preventative replacement of a degrading timing belt, including dropping the oil pan to clean rubber fibers out of the oil pickup strainer to prevent oil starvation.
Required to remove heavy carbon crusting on the intake valves of direct-injected EB2 engines, restoring lost power and curing engine misfires.
Oil burning caused by clogged piston rings or oil starvation can quickly poison the catalytic converter, requiring replacement to pass NZ Warrant of Fitness (WoF) emissions/dash light checks.
