2012 — 2015
1.6L I4 (EP6)
Petrol
Perform a cold start and listen closely to the top-right side of the engine bay. | Note: Listen for a metallic rattling or 'death rattle' sound when the engine is cold. The EP6 Prince engine is notorious for timing chain stretch and tensioner failure, which can lead to catastrophic engine damage if ignored.
Let the car idle for 5 minutes, then stab the accelerator pedal while watching the exhaust mirror. | Note: A puff of blue smoke indicates worn valve stem seals, a highly common issue on EP6 engines that causes excessive oil consumption and fouled spark plugs.
Drive at low speeds and check for jerky shifts or a 'Gearbox Fault' warning on the dash (if automatic). | Note: The AL4/AT8 4-speed automatic transmissions are prone to electrovalve failure and overheating. Jerky shifting from 1st to 2nd is a major red flag.
Run the cabin heater on high and check the footwells for dampness, and inspect the engine bay for sweet-smelling pink crust. | Note: The plastic thermostat housing on these models frequently cracks and leaks coolant, leading to overheating. Check the coolant expansion tank level before and after the drive.
Minor service including PSA-approved engine oil (5W-30 Total Quartz INEO ECS) and filter change. Inspect cabin filter and check for early-stage oil leaks around the valve cover.
Intermediate service. Replace spark plugs, air filter, and cabin filter. Conduct a comprehensive cooling system pressure test and inspect the timing chain slack via diagnostic tool or physical measurement.
Major milestone. Proactively replace the timing chain, guides, and tensioner. Replace the water pump, drive belt, plastic thermostat housing, and perform a carbon clean of the intake valves.
Check the engine oil level manually every 1,000 km; the EP6 engine can consume up to 1L of oil per 2,000 km even when healthy.
Use only high-grade, low-SAPS fully synthetic oil meeting PSA B71 2290 or B71 2312 specifications to prevent intake valve carbon buildup.
Flush the cooling system every 3 years using genuine Peugeot-approved coolant to prevent corrosion of the aluminum engine block.
Inspect the plastic water pump friction pulley mechanism (auxiliary belt tensioner) for wear or noisy bearings.
Scan the ECU for hidden 'super-knock' or misfire codes (P1336 to P1340) during routine servicing, which indicate carbon deposit issues.
Estimated repair costs if issues arise
Essential preventative maintenance if rattle is present. Requires specialist Peugeot timing tools to lock the camshafts.
Usually fails every 60,000 to 80,000 km. Best replaced with the updated metal-reinforced aftermarket unit if available.
Recommended if the vehicle suffers from rough idling, hesitation, or flat spots under acceleration due to direct injection carbon buildup.
