2006 — 2011
2.2L HDi (4HV)
Diesel
Listen for a distinct chuffing or ticking sound from the engine bay at idle and check under the plastic engine cover for a black, tar-like substance around the injectors. | Note: Known as the 'black death', this is caused by leaking injector copper washers. If left untreated, the injectors will seize solid into the cylinder head, making extraction extremely difficult and costly.
Accelerate hard uphill in third or fourth gear, checking for flat spots, hesitation, black smoke, or a sudden loss of power (limp home mode). | Note: The 2.2 HDi (4HV Puma engine) is highly prone to EGR valve carbon clogging and DPF blockage, especially if used primarily for short, urban delivery trips.
Engage all gears thoroughly during the drive, paying close attention to any crunching or stiffness when shifting into 2nd and 5th gears. | Note: The manual gearboxes in these vans suffer from fragile synchros and stretched selector cables. Hard shifting or popping out of gear indicates an impending gearbox rebuild.
Rest your foot lightly on the clutch pedal at idle to feel for excessive pulsations, and listen for a metallic rattling or chattering noise that disappears when the clutch is fully depressed. | Note: The Dual Mass Flywheel (DMF) is a common failure point on these high-torque commercial vehicles. Failure can lead to starter motor damage or severe gearbox housing wear.
Minor service: Change engine oil using low-SAPS 5W-30 oil to protect the DPF. Replace oil filter, inspect front brake wear, and check cabin air filter.
Intermediate service: Replace the fuel filter (critical for protecting high-pressure injectors), air filter, and brake fluid. Inspect suspension bushings and ball joints.
Major service: Perform a comprehensive inspection of the timing chain and tensioner. Replace the gearbox oil, engine coolant, accessory drive belts, and inspect the DPF load state.
Always use high-quality, low-SAPS 5W-30 engine oil specifically rated for Peugeot/Citroën (PSA B71 2290) to prevent premature DPF clogging and timing chain wear.
Drain the fuel filter water separator at every service to prevent moisture from damaging the highly sensitive common-rail high-pressure fuel pump.
Ensure copper injector washers are replaced proactively every 80,000 km, and apply ceramic anti-seize paste to the injector bodies to prevent seizing.
Perform a highway run (at least 30 minutes at speeds over 80 km/h) fortnightly to allow the DPF to complete a passive regeneration cycle.
Inspect and clean the main engine-to-chassis earth strap annually; corrosion here is a notorious cause of mysterious dashboard warning lights and starting issues.
Estimated repair costs if issues arise
If the copper washers leak and cause the injectors to seize, specialized hydraulic extraction tools are required. In worst-case scenarios, the cylinder head must be removed.
A labor-intensive job requiring the removal of the subframe and gearbox. It is highly recommended to replace the slave cylinder and rear main crank seal at the same time.
While the 4HV engine uses a timing chain, the hydraulic tensioners are prone to wearing prematurely. Replacing this preventatively avoids catastrophic engine failure.
